Image Sensor: 1/3” Progressive Scan CMOS Sensor
Lens: Focal Length: 1.18 mm, Aperture: F1.8
Field of View: 160° (Diagonal), 135° (Horizontal), 109° (Vertical)
Night Vision: 850 nm IR LED (25 ft / 7.6 m)
Full-Color Night Vision: Yes
Lighting: Built-in Spotlights
Interface & Button: 1× RESET Button, 1× Doorbell Button, 1× Anti-Theft Button
Maximum Resolution: 2K 3MP (2304 × 1296px)
Frame Rate: 15 fps
Digital Zoom: 10x
Video Compression: H.264
Live View: Yes
Image Enhancement: 3DNR, WDR
Audio Input & Output: Built-in Microphone and Speaker
Audio Communication: Two-Way Audio with Noise Cancellation
Local Storage: MicroSD Card Slot on Camera (Up to 512 GB)
Cloud Storage: Tapo Care Cloud Storage Services (Subscription required)
Sensor: Dual PIR Motion Sensor (FOV: 150° horizontal), One Ambient Light Sensor
AI Detection: Person Detection
Activity Zones: Yes
Output Notification: System Notification, System Notification with Snapshot (Tapo Care Services)
Network Connectivity: Connect via Wi-Fi
Wireless Connectivity: IEEE 802.11b/g/n, 2.4 GHz Wi-Fi
Security: On-Device Machine Learning, 128-bit AES Encryption with SSL/TLS, WPA/WPA2-PSK
Power Source: 6400 mAh Built-in Rechargeable Lithium-ion Battery
Optional Solar Panel: Tapo A201 (Sold separately)
Input Voltage: Doorbell Battery Pack Adapter Input: 100-240 V, 50/60 Hz
Output Voltage: Doorbell Battery Pack Adapter Output: 5.0 V, 1.0 A
Smart Integration: Google Assistant, Amazon Alexa
Weather Resistance: IP65
System Requirements: Tapo App: iOS 12.0 or higher, Android 4.4 or higher
Mounting Options: Stick to a Wall, Mount to a Wall
Operating Temperature: -20℃~45℃
Storage Temperature: -40℃~60℃
Operating Humidity: 10% 90% RH, Non-condensing
Dimensions (W × D × H): Doorbell Dimensions: 2.13 × 1.97 × 1.52 in (150 × 50 × 38.4 mm)
