HARDWARE FEATURES
Interface: 1 Gigabit Ethernet Port
Button: WPS Button, Reset Button
Input Power: 100-240V~50/60Hz
Max. Power Consumption: 10W
Dimensions (W x D x H): 2.9 × 1.8 × 4.9 in. (74.0 × 46 × 124.8 mm)
Antenna: 2 External Antennas
WIRELESS FEATURES
Wireless Standards: IEEE 802.11a/n/ac/ax 5GHz, IEEE 802.11b/g/n 2.4GHz
Frequency: 2.4GHz and 5GHz
Signal Rate: 300 Mbps at 2.4GHz, 1200 Mbps at 5GHz
Working Modes: Range Extender / Access Point
Reception Sensitivity:
5GHz:
11a 6Mbps: -93dBm
11a 54Mbps: -75dBm
11ac HT20 MCS0: -92dBm
11ac HT20 MCS8: -70dBm
11ac HT40 MCS0: -90dBm
11ac HT40 MCS9: -66dBm
11ac HT80 MCS0: -87dBm
11ac HT80 MCS9: -62dBm
2.4GHz:
11g 54Mbps: -77dBm
11n HT20 MCS7: -75dBm
11n HT40 MCS7: -72dBm
Wireless Functions: Enable/Disable Wireless Radio, Wireless Statistics
Wireless Security: 64/128-bit WEP, WPA/WPA2-PSK encryptions
Transmission Power: CE: 2.4GHz ≤20dBm, 5GHz ≤30dBm
OTHERS
Certification: FCC, RoHS
Package Content: Wi-Fi Range Extender RE505X, Quick Installation Guide
System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux. Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
Certifications: FCC, RoHS
Environment: Operating Temperature: 0℃~40℃ (32℉ ~104℉), Storage Temperature: -40℃~70℃ (-40℉ ~158℉), Operating Humidity: 10%~90% non-condensing, Storage Humidity: 5%~90% non-condensing
